Version: 1.06 125
18.3. CPU-16 bits
References:
MS-CPU16
Hardware on all models:
Power supply input
Button for selection of the mode of working
RS232
RS485
I/O for synchronization
Internal temperature measurement
Input voltage measurement
Ethernet
T
ECHNICAL
S
PECIFICATIONS
General
Processor 16 bits, 7.37 Mips
Clock Real Time Clock, backed-up (see schema following)
Button Push button : RUN - STOP - RESET
Power Supply
Voltage 6 .. 30 VDC
Supply Current Maximum: 1 A (on 3.3 Volts of the BUS)
Consumption 200 mA
