Techno Trade TBOX MS - Page 124

Version: 1.06 124
24 Vdc Power supply
Description:
Power Supply 24 VDC
Connector: POWER UNIT
Screw connector (4 x 5.08 mm)
Description:
Power Supply - 48 VDC
Connector: POWER UNIT
Screw connector (4 x 5.08 mm)
Description:
Battery
Connector: POWER UNIT
S CREW CONNECTOR (5 X 5.08)
- 48 Vdc Power supply
Description:
Power Supply – 48 VDC
Connector: POWER UNIT
Screw connector (4 x 5.08 mm)
1 2 3 4
Gnd
0
V
-60 .. -24 VDC
earth
V-
1 2 3 4
Gnd
+24V
Earth
Gnd
+8 .. +30 VCC
-48V
Terre
1 2 3 4
Gnd
+24V
Earth
Gnd
-60 ..
–
24 VCC
-48V
Terre
1 2 3 4
+Bat
Batter
y
5
+24V
Gnd
12/24 V backup
24
V
Gnd
UPS
For electrical security reason, you
have to manipulate connectors with
power switched OFF.
