Version: 1.06 44
8.4. Info properties
You can enter a version number, the name of the programmer and a description of your
program.
This information is not sent to TB
OX
MS.
8.5. Advanced
8.5.1. Startup
By Startup we mean:
Reset of RTU (hardware or software)
Sending of Program
Under those conditions two mechanisms of the RTU can be customized.
Reset all physical outputs: when active, at startup the RTU reinitializes the
outputs to ‘0’. After that the outputs are monitored
according to the process.
When not active, at startup the outputs are
maintained to their last status. After that the outputs
are monitored according to the process.
Wait start of condition: this feature relates to alarm condition.
The mechanism of generating alarm is based on transition:
the changing of a digital Tag or the overstepping of an
analog threshold.
This option allows changing this rule at startup:
With ‘Wait start of condition’ active:
With ‘Wait start of condition’ not active:
if the alarm condition is true at startup, an internal
‘start of alarm - auto-ack’ is generated. When the alarm
condition disappears, the alarm is generated.
startup
Alarm Alarm
time
time
startup
Alarm Alarm
Internal
Alarm
Alarm
