Version: 1.06 68
10. Tags
A Tag is essential for any programming
• An alarm is conditioned from a Tag.
• The Datalogging mechanism records values of Tags.
• BASIC/Ladder programming executes a process by handling Tags.
• …
Any variable of the
TB
OX
MS
that you want to use in any configuration, you have to
declare it as a Tag.
There are 3 types of variables:
• The Physical I/O (DI, DO, AI, AO)
• The System Variables (predefined analog and digital functions)
• The Internal variables, digital and analog (aka Registers)
The Tags are gathered in the folder Tags of the Project Workspace:
The Tags can be sorted into Groups of Tags.
From the list of Tags, right click.
From the Context menu, select ‘New → Group’.
You can then move/create Tags into the Group.
GROUP of Ta
