Version: 1.06 136
16 x Digital Inputs (next)
Isolation
2 groups isolated Isolation by group of 8 inputs
From the Ground Isolation from the CPU ground and the earth
Level of isolation 1500 Vrms
- between group
- between Inputs and ground
- between Inputs and earth
Protection
Test Automatic test of the access of the card by the CPU
(see LED ‘CS’ above)
RC filter 1592 Hz
Voltage inversion Up to 55 VDC
Protection EMC
Voltage at input
Typical 24 VDC
Maximum for a LOW level 5 VDC
Minimum for a HIGH level 11 VDC
Maximum 60 VDC
Current
Maximum at the input 2.0 mA at 30 VDC
4.5 mA at 60 VDC
Resistance Typical: 12 k
Consumption of the card 40 mA
Sampling
Minimum period LOW – HIGH 20 msec – 20 msec. (10msec for hardware and 10 msec for software)
Frequency (software) At each cycle of BASIC / Ladder
Temperature
Storage -40° to 70 °C
Working (ambient) Standard: -5°C to 50°C
Ruggedized: -20 °C to 70 °C
Hygrometry 15 to 95 % without condensation
Dimensions
Without connector Height x length x Depth: 150 x 83 x 29 mm
Weight 254 gr
