Techno Trade TBOX MS - Page 138

Version: 1.06 138
16 x Digital Inputs (next)
Cabling to Dry contact
Cabling to NPN transistor
Cabling to PNP transistor (or OPTO)
Cabling to Voltage sensor
Sensor
V -
Input x
Input x
V-
V+
V-
Input x
V -
R
R : 1 k (12 VDC)
10 k (24 VDC)
V+
V-
Input x
V -
V+
V-
