Version: 1.06 143
16 x Digital Inputs/Outputs (next)
T
ECHNICAL
S
PECIFICATIONS
General
Quantity 16 channels. Each can be cabled as Input or Output
Replacement Hot insertable/removable. There is no risk to damage hardware,
but a reset is required.
Consumption of the card Tbd
Test Automatic test of the access of the card by the CPU
(see LED ‘CS’ below)
LED
Individual LED corresponding to the activation of each input or output.
By software, possibility to disable the LED to save energy
CS Card Selection: the card corresponds to a card declared in TWinSoft.
ER Error: The type of the card does not correspond to the one declared
in TWinSoft.
Isolation
2 groups isolated Isolation by group of 8 inputs
Isolation from the Ground Isolation from the CPU ground and the earth
Level of isolation 1500 Vrms
- between group
- between Inputs and ground
- between Inputs and earth
Temperature
Storage -20 to 70 °C
Working (ambient) Standard: -5°C to 50°C
Ruggedized: -20 °C to 70 °C
Hygrometry 15 to 95 % without condensation
Dimensions
Without connector Height x length x Depth: 150 x 83 x 29 mm
Weight 258 gr
