Version: 1.06 166
8 Relay Outputs (next)
T
ECHNICAL
S
PECIFICATIONS
General
Quantity 8 outputs
Consumption Tbd
Replacement Hot insertable/removable. There is no risk to damage hardware, but
a reset is required.
Test Automatic test of the access of the card by the CPU
(See LED ‘CS’ below)
LED
CS Card Selection: the card corresponds to a card declared in TWinSoft.
ER Error: The type of the card does not correspond to the one declared in
TWinSoft.
Voltage
With DC Max: 30 Vdc at 3A
With AC Max: 250 Vac
Current
DC 3 A
AC 3 A
Operating live
At full resistive load 100000 operations
Protection
To an external relay When the relay drives an external relay, the latter must be protected
with a diode (if DC relay) or a RC circuit (if AC relay)
Isolation
Individual Each relay is totally isolated from the rack and other relays .
Voltage of isolation: 3 KV
Temperature
Storage -20°C to 70°C
Working (ambient) Standard: -5°C to 50°C
Ruggedized: -20 °C to 70 °C
Hygrometry 15 to 95 % without condensation
Dimensions
Without connector Height x Length x Depth: 150 x 83 x 29 mm
Weight 300 g
