Techno Trade TBOX MS - Page 170

Version: 1.06 170
4 Analog Input Isolated (next)
C ABLING – I SOLATED AI
Description: Connector:
Screw connector
Pin Out:
1 input 0: 4..20m (+)
2 input 0: 4..20m (-)
1 input 1: 4..20m (+)
2 input 1: 4..20m (-)
1 input 2: 4..20m (+)
2 input 2: 4..20m (-)
1 input 3: 4..20m (+)
2 input 3: 4..20m (-)
1 2
1 2 1 2
1 2
