Version: 1.06 33
Other possibilities of PC Setup:
• Offline: this option avoid sampling TB
OX
MS
• Local: you select a serial port of the PC (typically RS232). The Baudrate must fit
with the port of TB
OX
MS you are connected to.
• TCP/IP: to establish a communication in TCP/IP, typically through the Ethernet port
of TB
OX
MS. TWinSoft will establish a connection with the IP address of the
‘Ethernet’ port of the CPU (see chapter 9.1: ‘
CPU resources
’).
From this
PC Setup
menu, it is also possible to specify another IP address,
for instance if communicating to another Ethernet port or through GPRS.
• Modem: to establish a remote connection to the TB
OX
MS. TWinSoft takes full
advantage of Windows' built-in modem support: simply install your modem
in the control panel's Modems applet of Windows and you are ready to call
your TB
OX
MS.
If your PC is equipped with USB port,
you can use a converter USB-RS232
You can develop your TWinSoft document without
connection to the
TB
OX
MS, but it will be
mandatory to send it to have the RTU running!
The program can be sent through RS232, RS485,
Ethernet or modem.
