Version: 1.06 73
You type a Tag Name, a Comment and select as Type: ‘Internal Register’
For each Analog Register, the formats available are:
o 8 bits (Signed or Unsigned)
o 16 bits (Signed or Unsigned)
o 32 bits (Signed or Unsigned)
o Float (IEEE 754)
The initial value is the value the Tag will have at the start up of TB
OX
MS.
If you leave the field empty, the value is maintained at start up.
ModBus Address is discussed in chapter 10.3
By default, TWinSoft creates Analog Internal Variable in
format ‘Float’.
Check it fits with the use you intend to have with the variable.
