DUT-E fuel level sensors. Operation manual. Version 8.1
© Technoton, 2020 17
1.4 Technical specifications
DUT-E is powered by on-board power supply of the Vehicle where it is installed.
DUT-E can be used in the conditions of temperate and cold climates.
For resistance to mechanical impact DUT-E is shake and shockproof.
1.4.1 Main specifications
Table 1 — DUT-E main specifications
Parameter, measuring unit
Value
Fuel level sensor operating principle
Capacitive
Relative measuring error (to the length of the
measuring part), %, not more than
±1.0
Power supply voltage range, V
10…50
Maximal current consumption at supply voltage
12/24 V, mA, not more than
50/25
150*/75*
Availability time after power-up, seconds,
not more than
10
Maximum trimming of the measuring probe
see 2.4
Maximum length increase, mm, not more than
see 2.5
Temperature range, °C
-40…+85
Ingress protection rating
IP55/57
Electromagnetic compatibility
see annex G
Weight, kg, not more than
0.6 (at L=1000 mm)
0.5 (at L=700 mm)
0.4 (at L=350 mm)
Overall dimensions, mm, not more than
see figure 8
* For DUT-E CAN.
