Accessories / Screen filter
DUT-E fuel level sensors. Operation manual. Version 8.1
© Technoton, 2020 90
5.3 Screen filter
The screen filter which is mounted at the end of DUT-E measuring probe (see figure 62 a) is
designed to protect its electrodes from water and mud. This allows to significantly enhance the
sensor service life (see DUT-E screen filter video).
Screen filter mounting order: firstly, put on fixator, then put on bottom stop and fix it with two
side screws. Put the screen filter over bottom stop and fasten it with a fixator locks.
(see figure 62 b).
a) mounting location
b) mounting order
Figure 62 — Screen filter
ATTENTION: Screen filter cannot be used without installed bottom spring stop.
