Technoton DUT-E AF - Service Cable

Configuration of sensor using service adapter / Service adapter components / RS-485 service cable
DUT-E fuel level sensors. Operation manual. Version 8.1
© Technoton, 2020 51
3.3.4 RS-485 service cable
RS-485 service cable used to connect adapter to DUT-E 485.
Table 10 — Pinout of RS-485 service cable connectors
View
Pin No
Wire
Signal
Marking
Color
Assignment
Type
6
GND
Brown
Ground
-
7
GND
Brown
Ground
-
10
485B
Red
Transmitted
data
Serial,
RS-485
interface
11
SEL1
Brown
RS-485
selection
Discrete
14
VBAT
Orange
Power supply
Analog,
voltage
0…50 V
15
485A
White
Received
data
Serial,
RS-485
interface
1
VBAT
Orange
Power
supply
Analog,
voltage
0…50 V
2
GND
Brown
Ground
-
3
485A
White
Received
data
Serial,
RS-485
interface
4
485B
Red
Transmitted
data
Serial,
RS-485
interface
