Configuration of sensor using service adapter
/ Service adapter components / Universal service adapter
DUT-E fuel level sensors. Operation manual. Version 8.1
© Technoton, 2020 49
3.3.2 Universal service adapter
Universal service adapter (hereinafter adapter) is designed to transmit data between
DUT-E sensors and PC.
1 – RS-232/ISO9141/RS-485 socket for DUT-E connection;
2 – TX yellow LED indicator of data transmitted to DUT-E;
3 – RX green LED indicator of data received from DUT-E;
4 – ON red LED indicator of power supply;
5 – USB B port for PC connection.
Figure 28 — Adapter exterior view
