Technoton DUT-E AF - Overall Dimensions

General information and technical specifications of DUT-E / Technical specifications / Overall dimensions
DUT-E fuel level sensors. Operation manual. Version 8.1
© Technoton, 2020 23
1.4.7 Overall dimensions
Figure 8 — DUT-E overall dimensions
* Nominal measuring probe length (350 mm/700 mm/1000 mm, see figure 1).
