1.4.5 Specifications of DUT-E CAN output signal
Parameters of DUT-E CAN output signal correspond to the specification of
CAN j1939/S6 Telematics interface. The data transfer protocol is based on SAE J1939 standard
and meets its requirements.
DUT-E CAN data is sent in automatic transmission mode and by request.
Output messages list of DUT-E CAN data transmission protocol can be found in table 3.
The configuration of CAN j1939/S6 interface parameters by the user is conducted via K-Line
interface (ISO 14230) using Service DUT-E service software.
S6 Technology allows to configure the summarization of parameters of up to 8 DUT-E CAN fuel
level sensors. For each sensor a unique network address (SA) from 101 to 108 should be
specified.
Table 3 — Messages of DUT-E CAN data transfer protocol
