Introduction

DUT-E fuel level sensors. Operation manual. Version 8.1

Introduction

Recommendations and rules set out in this Operation Manual apply to DUT-E fuel level

sensors (further on — DUT-E), models codes: 116 (for DUT-E CAN),

111 (for DUT-E 232), 115 (for DUT-E 485), 124 (for DUT-E AF), 112 (for DUT-E A5),

113 (for DUT-E A10), 114 (for DUT-E F), 068 (for DUT-E I) and SK DUT-E service adapter

(further on — SK DUT-E) manufactured by JV Technoton, Minsk, Republic of Belarus.

The model code of DUT-E is identified by the first three digits of its serial number printed at its

measuring probe or on its packing label:

The manual contains information on design, operation principle, specifications and instructions

on installation, use and maintenance of DUT-E. The manual defines SK DUT-E connection and

usage guidelines as well as Service DUT-E software (version 3.26 and higher) installation and

use.

are additional sensors within Telematics systems. DUT-E sensors are used

for accurate level measurement in fuel tanks of vehicles and stationary units.

SK DUT-E serves for data exchange between the sensor and the personal computer.

DUT-E features:

DUT-E key features:

• compliance with Units, Database and cabling system S6 Technology*;

• adjustable temperature correction for automatic measurement correction based on

ambient temperature**;

• function of digital self-diagnostics for sensor quality control**;

• measuring probe length extension up to 6 m with additional sections**;

• measuring probe length reduction without min/max recalibration***;

• ergonomic bayonet mount allows to save installation time;

• bottom spring for better mounting rigidity;

• screen filter for secure protection from water and mud ****;

• full set of mounting accessories and connection cable included;

• built-in voltage stabilizer – output signal does not depend on vehicle power supply

voltage;

• reverse polarity and short circuit protection of any output to vehicle electrical

system and chassis;

• sealing possibility to avoid unauthorized intrusion and tampering;

• conformity with European and national automotive standards;

• high-quality technical support and documentation.

* DUT-E CAN.

** DUT-E AF/232/485/CAN.

*** DUT-E A5/A10/F/I.

**** Starting from 01.09.2017 the screen filter is purchased separately.
