Configuration of sensor using service adapter / Vertical menu description / Settings - Operation modes
DUT-E fuel level sensors. Operation manual. Version 8.1
© Technoton, 2020 73
2) Message interval* — time period the sensor automatically send output message to the
tracking device.
Parameter value range is 1…255 seconds with 1 second step. Default value is 1 second.
3) Automatic transmission mode* – defines sensor output message type:
• Off - no automatic message transmission, sensor waits for tracking device request;
• HEX - automatic message transmission in binary format (used by default);
• ASCII - automatic message transmission in text format;
• ASCII EXT - automatic message transmission in extended text format. Additional Prefix
and Postfix configurable parameters are available for this mode to insert required
header or ending of the message.
4) Address ** - provides DUT-E with network address when several operate via single bus
(network). The following addresses are set by the Manufacturer by default:
• DUT-E 485 - two last digits of the sensor serial number;
• DUT-E CAN/AF - 101.
5) Summator*** — sets sensors network status when working in CAN summator mode
(see figure 49 e):
• Off - no need to summarize sensor values (default value);
• Master - should be selected for a sensor which has the highest decimal address in the
network;
• Slave - should be selected for all the other network sensors.
* Only for DUT-E 232/485.
** Only for DUT-E AF/CAN/485.
*** Only for DUT-E CAN.
