Configuration of sensor using service adapter / Vertical menu description / Settings - Calibration table
DUT-E fuel level sensors. Operation manual. Version 8.1
© Technoton, 2020 77
ATTENTION:
1) The number of calibration points is proportional to the measurement accuracy of
fuel volume. The recommended number of calibration pints is not less than 15.
You may add altogether 30 points into the calibration table.
2) The maximum possible fuel volume value that can be added into the calibration
table is 6556 l.
3) For DUT-E CAN, you can enter into the calibration table the point with the
maximum fuel level value not more than 3000 mm.
Click button to insert a new entry into the table and fill out the fields. Entries are
automatically sorted from low to high fuel level value. To delete an entry highlight it and click
button.
Clicking button will allow saving the table as a *.ttd file. To load
previously saved table from file click button.
RECOMMENDATION: After the sensor mounting in the tank, the end of its measuring
probe is located at a distance of 20…30 mm from the tank bottom. Some 10…30 l of
the remaining fuel which is not consumed is usually left in this dead zone which is not
accessible for monitoring. While creating the calibration table, we recommend to enter
for its first point (level of 0.0 mm) the value of the fuel volume which is equal to the
volume of not consumed fuel remaining in the tank.
