Configuration of sensor using service adapter / Vertical menu description / Settings – Analog output

DUT-E fuel level sensors. Operation manual. Version 8.1

To configure analog output, follow the instructions:

1) Enter value of the lower range limit into Minimum level (1.0…8.0 V) field.

2) Enter value of the higher range limit into Maximum level (2.0…9.0 V) field.

Diagnostics drop-down list (see figure 54 c) allows to enable/disable special output signal

diagnostics values:

• On — for U mode 0.5 V and 9.5 V voltage are diagnostics values according to table 20.

For F mode 400 Hz and 1600 Hz frequency are diagnostics values according to

table 21.

• Off — special diagnostics output values are disabled. Default setting.
