Radion 8140 Automatic Sprayer Control
OPERATION
Figure 2-18: Establish Tip Presets




TANK
Tank displays or give access to:
►Actual Content – displays the current volume of content in
the tank. Manual adjustment is directly relate to OEM tted
equipment. The volume cannot be manually adjusted if a Tank
sensor is active.
►Tank Filling – establishes the amount of actual and desired
material in the tank and the density of that material. Options
displayed directly relate to OEM tted equipment. Different
options will be available depending upon if a Tank sensor or
Fill Flow Sensor is active. See Settings->Machine->Filling for
additional information.
1. Press TANK
100
.
2. Press setting value to adjust settings as needed:
◄Actual Content (unavailable when Tank sensor is active)
◄Full Tank (unavailable when Tank sensor or Fill Flow Sensor
is active)
◄Density Type
◄Density Factor (available when Density Type is Fertilizer)
◄Desired Content (available when Tank sensor or Fill Flow
Sensor is active)
◄Automatic Filling (available when Tank sensor or Fill Flow
Sensor is active)
3. Press RETURN arrow to return to the Operation screen.
Figure 2-19: Tank Filling
