Radion 8140 Automatic Sprayer Control
SETTINGS
Import/Export data
Conguration and calibration data can be exported to USB drive and recalled for future use.
NOTE: The Import/Export buttons are not available for selection and are grayed out until a USB drive is inserted properly.
SETTINGS MENU STRUCTURE
| | | |
Job Parameters Machine OEM Diagnostics
Sensor Presence
Implement Parameters
Valve Setup
Tank Setup
Regulation Details
Clear Totals
Import/Export Calibrations
To import the calibration settings:
1. Insert USB drive.
2. Press IMPORT button .
NOTE: Only one (1) tank calibration settings file can be saved on
a USB drive at one time. If there is an existing file it will be
overwritten.
Figure 3-46: Import Data
To export the calibration settings:
1. Insert USB drive.
2. Press EXPORT button .
Figure 3-47: Export Data
