TeeJet RADION 8140 - Appendix C - Alarm Configurations

60
INTRODUCTION
www.teejet.com
OPERATION DATA SETTINGS TOOLSCONSOLE
Radion 8140 Automatic Sprayer Control
APPENDIX
APPENDIX C – ALARM CONFIGURATIONS
Code Message / Condition Possible Solution Console Path
1 No Flow Pulses
Check ow sensor from test menu. Check components and
programming steps related to ow.
Settings->Diagnostics->Test Inputs (1)->
Flow Sensor
2 Low Liquid Pressure
Check ow sensor from test menu. Check components and
programming steps related to ow.
Settings->Machine->Implement Parameters->
Tip Preset Setup (2) or Settings->Machine->
Calibrations or Settings->Diagnostics->Test Inputs
(2)->Liquid Pressure Sensor
4 Calibration Error
Check components and programming steps related to
implement or process registering a calibration error.
Settings->Machine->Calibrations - check sensors
5
Density Not Equal To Water
(1 kg/L or 8.34 lb/gal)
Select Water for tank contents or change Fertilizer density
No..Check components and programming steps related to
content.
Operation->Filling (1) or Settings->Machine->
Filling (1)
6 Below Minimum Speed
Increase speed. Check components and programming
steps related to speed.
Settings->Machine->Operation or Settings->
Machine-> Calibrations->Implement Speed Sensor
7 Pressure Based
Check components and programming steps related to
implement or process registering a pressure error.
Settings->Diagnostics->Test Inputs or Settings-> Machine-
>Implement Parameters->Tip Preset Setup (2)
8 Low Flow
Increase speed. Check or clean tips. Check components
and programming steps related to ow.
Settings->Diagnostics->Test Inputs or Settings-> Machine-
>Implement Parameters->Tip Preset Setup (2)
9 Tank Almost Empty
Rell tank. Check all components and programming steps
related to contents.
Operations->Tank->Filling (1) or Settings->
Machine-> lling (1) and (2) or Settings->
Machine-> Alarms-> Minimum Tank Contents
10 Target Rate Impossible to Reach
Select a new target rate. Use larger tips. Check
components and programming steps related to rates.
Operation->Target rates or Settings->Job Parameters
11 Actual Rate Too High
Select a lower target rate. Check components and
programming steps related to rates.
Operation->Target rates or Settings->Job Parameters
12 Minimum Regulation Pressure
Check components and programming steps related to
pressure.
Settings->Machine->Implement Parameters-> Regulation
Parameters
13 Maximum Regulation Pressure
Check components and programming steps related to
pressure.
Settings->Machine->Implement Parameters-> Regulation
Parameters
14 Pressure Too Low
Check components and programming steps related to
pressure.
Settings->Machine->Implement Parameters->
Tip Preset Setup (2)
15 Pressure Too High
Check components and programming steps related to
pressure.
Settings->Machine->Implement Parameters-> Tip Preset
Setup (2)
16 Pressure/Flow Check Check components and programming steps related to ow.
Settings->Diagnostics->Test Inputs or Settings-> Machine-
>Calibrations
19 Liquid Pressure Too Low
Check ow sensor from test menu. Check components and
programming steps related to pressure.
Settings->Machine->Implement Parameters->
Tip Preset Setup (2) or Settings->Machine->
Calibrations or Settings->Diagnostics->Test Inputs
(2)->Liquid Pressure Sensor
20 Liquid Pressure Too High
Check ow sensor from test menu. Check components and
programming steps related to pressure.
Settings->Machine->Implement Parameters->
Tip Preset Setup (2) or Settings->Machine->
Calibrations
21 No Speed Signal
Check components and programming steps related to
speed.
Settings->Machine->Calibrations->Implement Speed
Sensor
31 Work Not Possible
34 Save Error Insert or reset a USB device if saving to a USB port.
36 Can Speed Missing
Check GPS source for power/satellite reception. If no GPS
source, change speed source. Check components and
programming steps related to speed.
Settings->Machine->Operation->Speed Source
45 Boompilot Unit Not Responding
Check BoomPilot for power. Test BoomPilot under test
menu.
Settings->Diagnostics->Test BoomPilot
46 Boompilot Unit In Manual Mode
Current operation mode is different than standard
operation. If this is undesired, change mode to automatic
under test menu.
Settings->Diagnostics->Test BoomPilot
47 Not All Sections On
Current operation mode is different than standard
operation. If this is undesired, check section switches
are ipped up (ON). Check sections under test menus.
Congure sections. Check components and programming
steps related to power.
Settings->Diagnostics->Test Outputs (2) or Settings->
Diagnostics->Test Inputs (3)->Section Switches or Settings-
>Machine->Implement Parameters->Section Conguration
49 Section Output Failure
Check components and programming steps related to
sections.
Settings->Diagnostics->Test Outputs (2)
50 Master Output Failure
Check Master Switch if ipped up (ON). Check all
components and programming steps related to Master
Switch.
Settings->Diagnostics->Test Inputs (3)->Master Switch
