Radion 8140 Automatic Sprayer Control
APPENDIX
Code Message / Condition Possible Solution Console Path
51 Fill Valve Output Failure
Check ll valve under test menus. Check components and
programming steps related to ll valve.
Settings->Diagnostics->Test Outputs (2)->Fill Valve
52 Low Supply Voltage Check voltage supply under Diagnostics. Settings->Diagnostics->Supply Voltage
APPENDIX D – UNIT SPECIFICATIONS
Dimensions Radion 8140, 5-section 228.6 x 158.0 x 61.6 mm
Radion 8140, 7-section 228.6 x 158.0 x 61.6 mm
Radion 8140, 9-section 254.0 x 158.0 x 61.6 mm
Weight Radion 8140, 5-section 1.3 kg
Radion 8140, 7-section 1.3 kg
Radion 8140, 9-section 1.9 kg
Connector Power/CAN 8-pin Conxall
Speed/status 8-pin Conxall
Main 28-pin
Serial 9-pin
Environmental Storage -10 to +70°C
Operating 0 to +50°C
Humidity 90% non-condensing
Display Radion 8140 320 x 240 resolution 4.3"
Input/Output USB 2.0
Power Requirement < 9 watts @ 12 VDC
