Saving and Recalling Front-Panel Setups
TDS 340A, TDS 360 & TDS 380 User Manual
3–53
Using the Disk
The disk drive can provide mass storage for an unlimited number of oscilloscope
setups.
NOTE. Setups are not transferable between different oscilloscope models or
software versions.
To save a setup on a formatted disk, insert a formatted 720 Kbyte or 1.44 Mbyte
floppy disk into the slot at the top of the oscilloscope. Press the front-panel
button SAVE/RECALL, the main-menu button Save Setup, and then the
side-menu button To File. Use the general purpose knob to select the exact file
from the resulting scrollbar list. Finally, press the side-menu Save To Selected
File to complete the operation.
To recall a setup stored on disk, press the front-panel button SAVE/RECALL,
the main-menu button Recall Setup, and then the side-menu button From File.
Use the general purpose knob to select the exact file from the resulting scrollbar
list. Only files with .set extensions will be displayed. Finally, press the side-
menu Recall From Selected File to complete the operation.
Running the File Utilities
To run file utilities, see Using the File System on page 3–55.
