Appendix A: Specifications
TDS 340A, TDS 360 & TDS 380 User Manual
A–7
Table A–9: Typical characteristics — data handling
Name Description
Time, Data-Retention, Nonvolatile
Memory
1,2
≥5 Years
1
The time that reference waveforms, stored setups, and calibration constants are retained when there is no power to the
oscilloscope.
2
Data is maintained by a lithium poly-carbon monofluoride battery.
Nominal Traits
Nominal traits are described using simple statements of fact such as “Two,
identical” for the trait “Input Channels, Number of,” rather than in terms of
limits that are performance requirements.
Table A–10: Nominal traits — signal acquisition system
Name Description
Bandwidth Selections 20 MHz and FULL
Digitizers, Number of Two, identical, digitized simultaneously
Digitized Bits, Number of 8 bits
1
Input Channels, Number of Two, identical, called CH 1 and CH 2
Input Coupling DC, AC, or GND
Rang
ff
Chann
Volts/Div setting Offset range
2 mV/div – 99.5 mV/div ±1 V
100 mV/div – 995 mV/div ±10 V
1 V/div – 10 V/div ±100 V
Range, Position ±5 divisions
Range, Sensitivity
2
2 mV/div to 10 V/div
Rise Time TDS 340A: 3.5 ns
TDS 360: 1.75 ns
TDS 380: 875 ps
TekProbe Interface Level one probe coding
1
Displayed vertically with 25 digitization levels (DLs) per division and 10.24 divisions dynamic range with zoom off. A DL
is the smallest voltage level change that the 8-bit A-D Converter can resolve, with the input scaled to the volts/division
setting of the channel used. Expressed as a voltage, a DL is equal to 1/25 of a division times the volts/division setting.
2
The sensitivity ranges from 2 mV/div to 10 V/div in a 1–2–5 sequence of coarse settings. Between consecutive coarse
settings, the sensitivity can be finely adjusted with a resolution of 1% of the more sensitive setting. For example, between
50 mV/div and 100 mV/div, the volts/division can be set with 0.5 mV resolution.
