Appendix A: Specifications
A–10
TDS 340A, TDS 360 & TDS 380 User Manual
Table A–16: Nominal traits — mechanical characteristics
Name Description
Weight
Standard 7.0 kg (15.5 lbs) stand-alone instrument;
8.6 kg (19 lbs) with front cover, accessories, and accessories pouch installed;
12.9 kg (28.5 lbs) when packaged for domestic shipment
Rackmount 6.6 kg (14.5 lbs), plus weight of rackmount parts (Option 1R);
14.7 kg (32.5 lbs) when the rackmounted oscilloscope is packaged for domestic shipment
Rackmount conversion kit 4.5 kg (10 lbs); 7.5 kg (17.5 lbs) when kit is packaged for domestic shipment
Overall Dimensions
Standard Instrument (Figure A–1) Height: 191 mm (7.5 in) with feet and accessories pouch installed
165 mm (6.5 in) without the accessories pouch installed
Width: 362 mm (14.25 in) with handle
Depth: 471 mm (18.55 in) stand-alone instrument
490 mm (19.28 in) with front cover installed
564 mm (22.2 in) with handle extended
Rackmount Instrument Height: 178 mm (7 in)
Width: 483 mm (19 in)
Depth: 472 mm (18.6 in) without handles; 517 mm (20.35 in) including handles
