Controlling the Display
TDS 340A, TDS 360 & TDS 380 User Manual
3–29
You can display the current date and time on screen so that it appears in the
display, on hard copies you print, and with any files you store on the floppy disk.
To enable the date and time stamp in the display, do the following steps:
1. Press the front-panel button DISPLAY and then the main-menu button
Readout Options.
2. Press the side-menu button Display Date and Time to toggle the setting to
On.
3. The date and time are backed up by a battery and need not be set each time
you power up the oscilloscope. If the date and time are not correct, skip steps
4 and 5 and continue with step 1 of Setting the Date and Time on page 3–60.
Then redo this procedure.
4. Press Clear Menu to remove the menu from the display so the date and time
can be displayed. See Figure 3–39. (The date and time is removed from the
display when menus are displayed.)
5. Press HARDCOPY to print your date/time stamped hardcopy.
NOTE. To set the date and time, refer to Setting the Date and Time on page 3–60.
Add or Remove the
Date/Time Stamp
