Commands
TDS5000B Series Service Manual
5-15
CALibrate:FACtory:STEPSTATus
FAIL if the factory calibration failed
PASS if the factory calibration passed
CALIBRATE:FACTORY:STEPSTATUS
might return
:CALIBRATE:FACTORY:STEPSTATUS FAIL
indicating the last oscilloscope calibration step did not pass
CALibrate:FACtory:STEPSTIMulus
This command returns the required stimulus for this calibration.
CALibrate:FACtory:STEPSTIMulus
Using the format: <Volts>, <Freq>, <Chan>, <Term>, <Token>
Volts <NR3> is a floating point number representing DC volts if the value for
<Freq> is 0 or representing V
peak-to-peak
if the value for <Freq> is non-zero.
Freq <NR1> is the frequency in Hz of the applied waveform.
NOTE. This command typically returns the frequency of the signal in hertz.
However, if it returns a frequency value of “4” then that means apply the deskew
function of the Wavetek 9500 calibrator to all input channels. If it returns a “0”
then apply a DC voltage.
Chan <NR1> stands for the channel.
Term <NR1> stands for the ohms of termination. For example,
8.0E--03, 0, 1, 50, C01
means apply 800 mV DC to Channel 1 with 50 ohm termination. If the query is
sent before FACTORY CAL has been initialized, the returned string will be:
0.0, 0, 0, 0, END
Token is a unique string identifying the step to be done next.
Syntax
Returns
Example
Syntax
Returns
