Tektronix TDS5000B Series

Removal and Inst a l l a t i on Procedures
TDS5000B Series Se r vi c e Manual
6-- 49
Coaxial
cable (1)
T--15
TORX
screw (6)
Probe interface
circuit board
Acquisition circuit board
Disconnect ribbon cable from
the acquisition board
Coaxial
cable (2)
T--15
TORX
screw (6)
J1800
Figure 6--27: Acquisition circuit boa rd removal
