Mechanical Parts List
10- 2
TDS5000B Series Service Manual
Part s list column descriptions
Column Column name Description
1 Figure & index numbe r Items in this section are referenced by figure and index numbers to the exploded view
illustrations that follow.
2 Tektronix part num b e r Use this part number whe n ordering replacement parts from Tek tronix.
3and4 Serial number Column three indicates the serial number a t which the part was first effective. Column fo u r
indicates the serial number at which the pa rt was discontinued. No entry indicates the part is
good for all serial numbers.
5 Qty This indicates the quantity of parts u sed.
6 Name & description An item name is separated from the description by a colon (:). Because of space limitations, an
ite m nam e may sometimes appear as incomplete. Use the U.S. Federal Catalo g handbook
H6-1 for further item name iden tification.
Abbreviations conform to American National Standard ANSI Y1.1--1972.
Chassis-mounted parts and cable assemblies are located at the end of t he
Replaceable Electrical Parts List.
