Tektronix TDS5000B Series

Mechanical Parts List
TDS5000B Series Service Manual
10- 3
External Parts
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont ’d
Qty Name & description
10--1--1 200--4669--XX 1 DOOR :ACCESSORY TRAY,0.050 AL
200--4668--XX 1 CABINET,TOP: PRINTER TRAY,0.050 AL, Opt. 1P
--2 436--0408--XX B010100 B029999 1 TRAY,:ACCESSORY
--3 016--1935--XX 1 POUCH; ACCESSORIES,BLACK,SNAP--ON
--4 200--4832--XX 1 TOP:PLASTIC
--5 355--0303--XX 2 MARKER,IDENT; LABEL,PRINT UNIT ID,BLACK
--6 211--0722--XX 2 SCREW,MACHINE; 6--32 X 0.250,PNH,STL,C DPL,T--15 TORX DR
--7 348--1685--XX 4 FOOT:REAR, PC/ABS
--8 407--4961--XX 1 BRACKET; MOUNTING,POUCH ,0.050 AL
--9 200--4639--XX 1 COVER,SIDE:RIGHT,FR110
--10 200--4652--XX 1 COVER:CDROM,PC/ABS
--11 211--1050--XX B010100 B029999 8 SCREW,M ACHINE:6--32 X 0.312 L,PNH,STL CAD,T15
--12 333--4388--XX
333--4363--XX
1
1
PANEL ASSEMBLY:FRONT,LOWER,2 CH
PANEL ASSEMBLY:FRONT,LOWER,4 CH
--13 101--0158--XX 1 TRIM RING:FR 110 (PC/ABS)
101--0163--XX 1 TRIM RING; FR11 0 ,PC/ABS,OPTION FHD
--14 ------ ------ -- ---- 1 PEM
--15 200--4651--XX 1 COVER,FRONT:PC/ABS ALLOY BAYBLEND,FR110,TEK BLUE
--16 260--2746--XX 1 SWITCH ,KEYPAD:ELASTOMERIC,ON/STANBY,PUSHBUTTON
--17 200--4640--XX 1 COVER,SIDE:LEFT,FR110
--18 367--0528--XX 1 HANDLE, CARRYING:DUAL DUROMETER MOLDED,POLYPROPYLENE,VINYL GRIP
SECTION,
--19 407--4838--XX 1 BRACKET:HANDLE BASE,PC/ABS ALLOY,BAYER BAYBLEND FR--110,TEK BLUE
--20 212--0213--XX 1 SCREW,MACHINE:8--32 X 0.75 L,PNH,STL, BLACK OXIDE PL,TORX
--21 200--4667--XX 1 COVER:VGA PANEL,PC/ABS ALLOY,BAYER,BAYBLEND F R,TEK BLUE
--22 214--5003--XX 1 FASTENER,LATCHG:PUSH L OCK,1V60--3--9--999--9
--23 211--0738--XX B010100 B02 9 9 9 9 2 SCREW,MACHINE:6--32 X 0.625,PNH,STL BLK ZI,TOR X
