Tektronix TDS5000B Series

Mechanical Parts List
TDS5000B Series Service Manual
10- 7
Modules
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont ’d
Qty Name & description
10--3--1 650--4317--XX 1 PRI NTER,THERMAL:TDS50 0 0 SERIES PRINTER
--2 211--0738--XX B010100 B029 9 9 9 2 SCR EW, MACHINE:6--32 X 0.625,PNH,STL BLK ZI,TORX
--3 174--4427--XX 1 CA ASSY, SP:DESCRETE,CPD,20, 18 AWG, 8.0L, 2 X 10, RCPT,STR,2X10 BOTH ENDS
--4 174--4514--XX 1 CA ASSY,SP:GPIB,RIBBON
--5 039--0154--XX B010100 B019999 1 MOTHER BOARD ASSY;PENTIUM 4/CELERON BD,UATX,ASHLAND 2.1,W/O PROC-
ESSOR, D845GVAD2L
039--0159--XX B020000 B029999 1 MOTHER BOARD ASSY;PENTIUM 4/CELERON BD,UATX,LA CROSSE,W/O PROC-
ESSOR, BL KD865GLC L K INTEL P/N,SAFETY CONTROLLED
039--0173--XX B030000 1 MOT HER BOARD ASSY;PENTIUM 4,UATX,TAPPEN BD,GIG E, PROCSSOR LGA775,DDR2
667MHZ,TOTAL 4 GIG;BLKD945GTPLKR,SAFETY CONTROLLED
--6 156--9442--XX
167--0428--XX
B010100
B030000
B029999 1
1
IC ,MEMORY; 64M X 64,512M, 266 MHZ,CL=2.5,PC2100; MT16VDDT6464A,DIMM184
IC ,MEMORY; 64M X 64,512 MB DDR2,1.8V, 3--3--3;MT16HTF6464AY--40E,DIMM240,DS1
--7 211--1050--XX B010100 B029 9 9 9 1 6 SCR EW, MACHINE:6--32 X 0.312 L,PNH,ST L CAD,T15
--8 174--4894--XX
174--4865--XX
174--5351--XX
B010100
B020000
B030000
B019999
B029999
1 CABLE ASSY; 4 PIN P4 POWER,9.5 L,MOTH ER BOARD TO INTERFACE BOARD
CABLE ASSY; 4 PIN P4 POWER,9.5 L,MOTH ER BOARD TO INTERFACE BOARD
CABLE ASSY; 4 PIN P4 POWER,12 L,MOTHER BOARD TO INTERFACE BOARD
--9 174--4807--XX 1 CA ASSY; ATX USB, PLUS MISC. TO DISPLAY
--10 671--5737--XX 1 CIRCUIT BD ASSY; PC INTERFACE
--11 119--6480--XX
B010000
B010000
B010000
B010000
B010000
B010000
B010004
B010005
B010020
B010005
B010029
B010152
1 POWER SUPPLY:300W,AC--DC,STANDARD,ATX PC SUPPLY,90--132 180--264VAC 50--60 HZ
IN,+3.3V 16A +5V 26
TDS5 0 3 2 B
TDS5 0 3 2 B
TDS5 0 3 4 B
TDS5 0 5 2 B
TDS5 0 5 4 B
TDS5 1 0 4 B
119--6969--XX
All mili tary and commercial pro d u cts released w ith 119--6969--xx, ecept for a limited n u mber of
products lis ted above .
POWER SUPPLY; 300W, AC--DC, ATX POWER SUPPLY, 100--240 VAC 50--60 HZ, 115 VAC
400 HZ IN,
--12 614--1023--XX 1 PANEL ASSEMBLY:FRONT,4 C H--NO TS
614--1024--XX 1 PANEL ASSEMBLY:FRONT,2 C H
614--1025--XX 1 PANEL ASSEMBLY:FRONT,2 C H--NO TS
614--1026--XX 1 PANEL ASSEMBLY:FRONT
--13 366--0837--XX 7 KNOB,CAP; 0.650 D,SOFT FEEL COATING,PC/ABS BAYBLEND,FR110,TEK SILVER GRAY
--14 366--0836--XX 7 KNOB,CAP; 0.425 DIA,SOFT FEEL COATING,PC/ABS,BAYBL END,FR110,TEK SILVER GRAY
--15 366--0835--XX 1 KNOB,EPS; PUSH BUTTON ENCODER,SOFT FEEL COATING, PC/ABS BAY-
BLEND,FR110,TEK SILVER GRAY
--16 174--4321--XX 1 CABLE ASSY:FL AT FLEX,26POS,10.4L,FRONT PANEL
--17 259--0155--XX 1 FLEX CIRCUIT; POWER SWITCH,W/LED
--18 650--4633--XX 1 MODULE ASSEMBLY; TOUCH PANEL;TDS5000B SERIES
--19 650--4586--XX B010100 B0299999 1 COMPONENT KIT:DISPLAY MODULE ONLY
650--4999--XX B030000 1 COMPONENT KIT:DISPLAY MODULE ONLY
--20 343--1676--XX 1 CLAMP,CABLE; PC /ABS ALLOY,SILVER GREY
