Mechanical Parts List
10- 8
TDS5000B Series Service Manual
Modules (Cont.)
Fig. &
index
number
Name & d escriptionQty
Serial no.
discont ’d
Serial no.
effective
Tektronix part
number
-- 2 1 671--5279--XX
671--5244--XX
671--6299--XX
B010100
B030000
B029999
1 CKT BD SUBASSY:DISPLAY INTERFACE ONLY
CKT BD SUBASSY:DISPLAY INTERFACE ONLY
CKT BD SUBASSY;DISPLAY ,INTERFACE, TOUCH SCREEN
--22 119--6260--XX
119--6806--XX
B010100
B020000
B019999 1
1
POWER SUPPLY:INVERTER BOARD,FOR NEC 10.4 IN LCD
POWER SUPPLY;INVERTER BOARD,FOR NEC 10.4 I N LCD
--23 174--3618--XX B010100 B019999 1 CABLE ASSY SP:RIBBON,CPR,28 AWG,9.5 L,1X5,0.049CTR, LZ SERIES,MOL EX 50058 S
174--5278--XX B020000 B029999 1 CABLE ASSY SP; RIBBON,;CPR,28 AWG,9.5 L,1X5 ,0.049CTR,LZ SERIES JAE X 1X5 TO
1X8,0.049CTR,MOLEX 50058 SERIES
174--4794--XX B030000 1 CA ASSY; DISPLAY ADAPTER TO INVERTOR,SAFETY CONTROLLED
--24 174--4892--XX 1 CA ASSY,SP; RIBBON,IDC,50,2 8 AWG,13.0L,2 X 25,0. 0 3 9 CTR BOX MTE 30 GOLD X 2 X 25
0.039 CTR BOX MTE 30 GOLD
--25 210--0164--XX 8 RIVET,SOLID:0.163 OD X 0.415 L,PANEL RANGE HEAD STYLE,NYLON
--26 119--6441--XX 2 FAN,TUBEAXI AL :12VDC,0.15A,1.8W,48CFM,2450RPM,30DBA,92MM X 92MM X 26 MM, W/
7IN LEADS & CONNECTO
--27 174--4531--XX B010100 B029999 1 CABLE:PRINTER
--28 214--5119--XX
214--5064--XX
B010100
B020000
B019999
B029999
1 HEAT SINK,SEMIC; IC,PR OCESSOR;ALUMINUM WITH 12V FAN FOR I NTEL PENTIUM 4
PROC ESSOR,FOR LGA775 PACKAGE USE;COOLER MASTER S3N--9IWLS--06--GP,SAFETY
CONTROLLED
HEAT SINK,SEMIC; IC,PROCESSOR;ALUMINUM WITH 12V FAN FOR INTEL PENTIUM 4
PROC ESSOR,W/ THERMAL CONDUCTIVI TY GREASE,0.42 DEG C/W;COOLER MASTER
E2U--N73EC--03,SAFETY CONTROLLED
--29 119--7333--XX B03000 0 1 P4 LGA775 FAN--SINK--BRACKET FROM AVC.
