Tektronix TDS5000B Series User Manual

Operating Basics
32 TDS5000B Series Quick Start User Manual
Starting and Stopping an Acquisition
After you have a waveform displayed and the channels you want to acquire are selected, use the following
procedure.
1. Press the front-panel RUN/STOP
button to start the acquisition.
2. Press the RUN/STOP button again
to stop the acquisition.
3. To take a single acquisition, press
the Single button.
3
2
1
