Setting the Graticule Style
Use for quick estimate of
waveform parameters.
Use for making quick
estimates of waveforms
while leaving more room
on the display for auto-
matic readouts and other
data.
Use for full-screen mea-
surements with cursors
and automatic readouts
when cross hairs are not
needed.
Use with automatic read-
outs and othe r screen
text when display fea-
tures are not needed.
Use for NTSC video sig-
nals.
Use for v ideo signals
other than NTSC.
To set the graticule style select
Display > Graticule Style, and then
select one of the following styles:
Quick Tip
H To quickly change the graticule style, right-click anywhere in the graticule and then select Graticule Style
from the shortcut menu.
To Next Page
