Tektronix TDS5000B Series - Adding Screen Text

Operating Basics
TDS5000B Series Quick Start User Manual
53
Adding Screen Text
1. Select D isplay > Screen Text to
access the Screen Text Setup
control window.
1
2. Enter up to eight lines of text to
provide notes for screen shots,
printouts, or other users .
3. Click Display to turn the text dis-
play on and off.
4. Click Properties to open the Text
Properties control window for
positioning of the text on the dis-
play.
5. Click Clear to erase the entire text
of the selected line.
2
3
4
5
Quick Tips
H You can click and drag screen text to reposition it on the screen.
H To add text, right-click anywhere in the graticule, and then select Add Screen Text....
