TROUBLESHOOTING & REPAIR PROCEDURES Model 400E Ozone Analyzer
Instruction Manual
264 P/N 04316 Rev: B
11.5.8.2. Troubleshooting Analyzer/Modem or Terminal
Operation
These are the general steps for troubleshooting problems with a modem connected
to a T-API analyzer.
Check Cables for proper connection to the modem, terminal or computer.
Check to make sure the DTE-DCE is in the correct position as described in
Section 6.9.4.
Check to make sure the Set up command is correct.
Verify that the Ready to Send (RTS) signal is at logic high. The M400E sets
pin 7 (RTS) to greater than 3 volts to enable modem transmission.
Make sure the BAUD rate, word length, and stop bit settings between modem
and analyzer match, see Section 6.9.6.
Use the RS-232 test function to send “w” characters to the modem, terminal
or computer; See Section 6.9.7.
Get your terminal, modem or computer to transmit data to the analyzer
(holding down the space bar is one way); the green LED should flicker as the
instrument is receiving data.
Make sure that the communications software or Terminal emulation software
is functioning properly.
Further help with serial communications is available in a separate manual “RS-232
Programming Notes” T-API part number 013500000.
