Model 400E Ozone Analyzer
Instruction Manual
Operating Instructions
P/N 04316 Rev: B 71
6.4.3. Turning on the Reference Detector Option
If the IZS feedback option is purchased the analyzer must be told to accept data
from the Reference Detector and actively adjust the IZS output to maintain the
reference set point(s) previously chosen by the user (see Sections 6.4.1 & 6.4.2).
To perform this operation:
EXIT ignores the
new setting.
ENTR accepts
the
new setting.
SAMPLE RANGE = 500.0 PPB O3 =XXX.XX
< TST CAL CALZ
CALS
SETUP
SETUP X.X O3 GEN MODE:CNST
CNST
REF
ENTR EXIT
•
CNST - Constant Mode: In this mode, the analyzer sets the
O
3
Generator drive voltage at a constant level.
•
REF
- Reference Mode: In this mode, the analyzer uses
feedback from the O
3
Reference Detector to adjust the DO3
Generator Drive Voltage and stabilize the O
3
Generator
Output.
SETUP X.X
CFG ACAL DAS RNGE PASS CLK
MORE
EXIT
SETUP X.X
COMM VARS DIAG
O3
HALT
SETUP X.X
O3 CONFIG
MODE
ADJ DARK
EXIT
