Teledyne 400E - Analog Output (Step Test)

Operating Instructions Model 400E Ozone Analyzer
Instruction Manual
96 P/N 04316 Rev: B
6.7.2. Analog Output (Step Test)
This test can be used to assure the analog outputs are calibrated and working
properly. The test forces the A1, A2 and A4 analog output channels to produce
signals ranging 0% to 100% of whatever the range in which they are set in 20%
increments. This test is useful for verifying the operation of the datalogging/
recording devices attached to the analyzer.
To begin the Analog Output Step Test press:
SAMPLE RANGE = 500.0 PPB O3 =XXX.X
< TST TST > CAL
SETUP
SETUP X.X
CFG DAS RNGE PASS CLK
MORE
EXIT
SETUP X.X
COMM VARS
DIAG
HALT EXIT
Exit at Any
Time to Return
to main the
Sample Display
DIAG SIGNAL I / O
NEXT
ENTR EXIT
Exit 2X’s
to Return
to the
Diag Menu
SETUP X.X ENTER DIAG PASS: 818
8 1 8 ENTR
EXIT
DIAG ANALOG OUTPUT
PREV NEXT
ENTR
EXIT
DIAG AOUT ANALOG OUTPUT
0%
EXIT
Performs
Analog Output
step test.
0% - 100%
DIAG AOUT ANALOG OUTPUT
[0%] EXIT
Pressing the key under the STEP % will
pause the Test.
Brackets will appear Around the Step %:
EXAMPLE [20]
Pressing the same key again will resume
the Test.
