Teledyne 400E - Table 6-5: Test Functions Available to the A4 Analog Output Channel

Operating Instructions Model 400E Ozone Analyzer
Instruction Manual
80 P/N 04316 Rev: B
The Test Functions available to be reported are:
Table 6-5: Test Functions available to the A4 Analog Output Channel
Test Channel Zero Full Scale
NONE Test Channel is turned off
PHOTO MEAS 0 mV 5000 mV*
PHOTO REF 0 mV 5000 mV*
O3 GEN REF 0 mV 5000 mV*
SAMPLE PRESS 0 "Hg 40 "Hg
SAMPLE FLOW 0 cc/m 1000 cc/m
SAMPLE TEMP 0 C° 70 C°
PHOTO LAMP TEMP 0 C° 70 C°
O3 SCRUB TEMP 0 C° 70 C°
03 LAMP TEMP 0 mV 5000 mV
CHASSIS TEMP 0 C° 70 C°
* This refers to the internal voltage level of the function NOT the output
signal level of the Test channel itself.
Once a function is selected, the instrument not only begins to output a signal on the
A4 Analog Output, but adds TEST to the list of Test Functions viewable via the
Front Panel Display.
