Operating Instructions Model 400E Ozone Analyzer
Instruction Manual
76 P/N 04316 Rev: B
To set the ranges press following keystroke sequence:
.
SAMPLE RANGE = 500.0 PPB O3 =XXX.X
< TST TST > CAL SETUP
SETUP X.X
CFG DAS RNGE PASS CLK MORE EXIT
SETUP X.X RANGE CONTROL MENU
MODE SET UNIT EXIT
SETUP X.X RANGE MODE: SNGL
SNGL DUAL AUTO ENTR EXIT
EXIT Returns
to the Main
SAMPLE Display
SETUP X.X RANGE MODE:
SNGL DUAL AUTO
ENTR
EXIT
SETUP X.X RANGE CONTROL MENU
MODE
SET
UNIT
EXIT
SETUP X.X HIGH RANGE: 500.0 Conc
0 0 5 0 0 .0 ENTR EXIT
SETUP X.X LOW RANGE:
0 0 1 0 0 .0 ENTR EXIT
SETUP X.X RANGE CONTROL MENU
MODE SET UNIT EXIT
The LOW and HIGH
Ranges have separate
slopes and offsets for
computing the carbon
monoxide concentration.
The two ranges must be
independently calibrated.
Toggle the
Numeral Keys
limit of each
range.
