Teledyne 400E - Page 86

Operating Instructions Model 400E Ozone Analyzer
Instruction Manual
86 P/N 04316 Rev: B
To automatically calibrate an single analog channel, activate the ANALOG I/O
CONFIGURATION MENU, then press:
DIAG AIO CONC_OUT_2 CALIBRATED: NO
<SET CAL EXIT
DIAG AIO AUTO CALIBRATING CONC_OUT_2
DIAG AIO CONC_OUT_2 CALIBRATED:
YES
<SET CAL EXIT
DIAG ANALOG I / O CONFIGURATION
PREV NEXT
ENTR
EXIT
DIAG AIO AOUTS CALIBRATED: NO
< SET> CAL EXIT
DIAG AIO CONC_OUT_2 RANGE: 5V
SET>
EDIT EXIT
DIAG AIO CONC_OUT_2:5V, CAL
< SET SET>
EDIT
EXIT
DIAG AIO CONC_OUT_2 REC OFS: 0 mV
< SET SET> EDIT EXIT
DIAG AIO
CONC_OUT_2 AUTO CAL: ON
< SET SET> EDIT
EXIT
EXIT
to Return
to the main
Sample Display
Press SET> to select the
Analog Output channel to
be configured. Then Press
EDIT to continue
