Step 3 Configure QoS classification.
1. Choose Advanced Setup > Quality of Service > QoS Classification to enter the
configuration page, and click Add.
2. Traffic Class Name: Enter a name for the classification, which is VideoConference in this
example.
3. Rule Order/Rule Status: Keep the default values.
4. Ingress Interface: Select Local.
5. Ether Type: Select IP (0x800).
6. Protocol/UDP/TCP Destination Port: Select UDP, and set the UDP/TCP Destination Port to
1718:1720.
7. Specify Egress Interface (Required): Select the egress interface for the queue form the
drop-down list.
8. Specify Egress Queue (Required): Select the egress queue from the drop-down list.
9. Click Apply/Save.
