245
A.4
Factory settings
Parameter
Default Setting
Login Information
Login Method
HTTP (web UI)
Login IP
192.168.1
.1
Login User name/Password
admin/admin
Web Logout
3 minutes
Network Settings
Link Type
VDSL
Connection Type
PPPoE
IP Address Type
IPv4
Firewall
Enabled
NAT
Enabled
IGMP Multicast Proxy
Disabled
802.1P Priority
-1 (indicates disabled)
802.1Q VLAN ID
-1 (indicates disabled)
DSL Settings
DSL Link Type
EoA (include PPPoE, IPoE, and Bridge)
Encapsulation Mode for EoA
LLC/SNAP-BRIDGING
Encapsulation Mode for
PPPoA
VC/MUX
Encapsulation Mode for IPoA
LLC/SNAP-ROUTING
Scheduler for Queues of
Equal Precedence
Round Robin
Wireless Settings
Wireless feature
Enabled
Hide Access Point
Disabled
SSID
2.4GHz: Tenda_
XXXXXX
5GHz: Tenda_5G_
XXXXXX
XXXXXX
is the last six characters of the MAC address of
the modem router.
254
256
Table of Contents
Default Chapter
6
Table of Contents
6
1 Product Overview
11
Introduction
11
Features
11
Appearance
12
LED Indicators
12
Ports and Buttons
13
Label
14
2 Quick Setup
15
Connecting the Device to the Internet
15
Phone Cable Connection
15
Ethernet Cable Connection
16
3 G/4G Data Card
16
Connecting a Client to the Modem Router for Setup
17
Connecting a Wireless Client to the Modem Router
17
Connecting a Wired Client to the Modem Router
17
Setting up an Internet Connection
18
Login
18
Setting up the Internet Settings
18
Wireless Setup
27
Connecting to the Modem Router for Internet Access
28
Device Info
29
Summary
29
WAN Status
29
Xdsl Info
29
Device Info
30
Wan
31
Statistics
32
Route
34
Arp
35
Dhcp
36
4 Advanced Setup
37
Internet Settings
37
Setting the ATM Connection
37
Setting the PTM Connection
79
Setting the Ethernet Connection
85
Lan
91
Local Area Network (LAN) Setup
91
Connections Limited
96
Ipv6 Autoconfig
97
Vpn
102
Overview
102
Configuring Modem Router as a L2TP Client
102
Configuring Modem Router as a PPTP Client
105
Wan 3G/4G
108
Overview
108
Configuration Procedure
108
Nat
110
Virtual Server
110
Port Triggering
113
DMZ Host
115
Multi-NAT
116
Security
118
Dos Defence
118
IP Filtering
119
MAC Filtering
122
Parental Control
126
Time Restriction
126
URL Filter
127
Example of Configuring Parental Control
128
Alg
131
Bandwidth Control
133
Overview
133
Adding a Bandwidth Control Rule
133
Quality of Service
134
Qos Queue
135
Qos Classification
140
Example of Configuring Qos
141
Routing
146
Default Gateway
146
Static Route
146
Rip
148
Dns
150
DNS Server
150
Dynamic DNS
152
Dsl
155
Upnp
157
Overview
157
Configuring the Upnp Function
157
Storage Service
158
Overview
158
Enabling the Samba and FTP Servers
158
Example of Configuring the Storage Service Function
158
Interface Grouping
161
Overview
161
Example of Configuring Interface Grouping
161
Ip Tunnel
163
Ipv6Inipv4
163
Ipv4Inipv6
164
Ipsec
166
Overview
166
Configuring the Ipsec Function
170
Certificate
172
Local
172
Trusted CA
174
Multicast
175
Iptv
178
ATM Interface
178
ETH Interface
179
PTM Interface
179
5 Wireless
181
171
181
Basic
181
Security
183
MAC Filter
189
Wireless Bridge
190
Station Info
195
186
196
Basic
196
Security
198
MAC Filter
203
Wireless Bridge
205
Station Info
210
6 Diagnostics
211
Ping
211
Traceroute
212
Nslookup
213
Diagnostics
214
7 Management
215
Settings
215
Backup
215
Restore Backup
215
Restore Default
216
System Log
218
Overview
218
Viewing System Logs
218
Configuring System Logs
219
Passwords
221
Overview
221
Changing the Login Password
221
Snmp Agent
222
Overview
222
Configuring the SNMP Agent
223
TR-069 Client
224
Overview
224
Configuring the TR-069 Client
225
Internet Time
226
Overview
226
Synchronizing the System Time with the Internet
226
Access Control
227
Update Software
228
Overview
228
Upgrading the Firmware Locally
228
Upgrading the Firmware Using FTP Server
229
Upgrading the Firmware Using TFTP Server
230
Reboot
231
Appendix
232
Faq
232
Vpi/VCI List
233
A.2 Vpi/VCI L ist
233
Vlan List
243
A.3 VLAN List
243
Factory Settings
255
A.4 F Actory Settings
255
