Screw Torque Requirements
Table 5 Torque Requirements
Screw
Description
Tightening Torque MA
max [Nm]
Ft/Lbs
M 3 1.28 1
M 3.5 1.96 1
M 4 2.9 2
M 5 5.75 4
M 6 9.9 7
M 8 24 18
M 10 48 35
M 12 83 61
M 14 132 97
M 16 200 148
M 18 275 203
M 20 390 288
M 22 530 391
M 24 675 498
M 27 995 734
M 30 1350 996
M 33 1830 1350
M 36 2360 1741
M 39 3050 2250
Screw Tightening Torques
Property class 8.8 according to DIN ISO 898
