TGW Natrix - Chain Lubricator

To Next Page

To Previous Page

Natrix IOM

Chain Lubricator

Balloon No. Item Description Identifier

10.1 00048394 UNI OIL BRUSH SPR 6.5-PERLON C

10.2 00124848 WKS SPECIAL SPRAY 5KG T-10°/+80°C C

10.3 00254680

NATRIX CENTRAL LUBRICATING UNIT, NATRIX

CENTRAL LUBRICAT. UNIT INSTALLATION

DRAWING

10.4 00115988 RUBBER BUFFER 30/15/M 8 30-15-2 C

Chain Lubricator Replacement Parts
