TGW Natrix - Actuating Elements Right & Left Transfer

Natrix IOM
Actuating Elements Right & Left Transfer
Balloon No. Item Description Identifier
5.1 00228247
SWITCH POINT 30° PNEUMATIC RIGHT, SWITCH
POINT 30° PNEUMAT.RIGHT SYMMETRICAL
A
5.1 00210895
SWITCH POINT 30° PNEUMATIC RIGHT, SWITCH
POINT 22° PNEUMAT.RIGHT SYMMETRICAL
A
5.2 00212025
CENTRING BLOCK RIGHT, CENTRING BLOCK
RIGHT SYMMETRICAL PAS-80X
B
6.1 00228260 SWITCH POINT 30° PNEUMATIC LEFT A
6.1 00210894 SWITCH POINT 22° PNEUMATIC LEFT A
6.2 00212024 CENTRING BLOCK LEFT B
Actuating Elements Right & Left Replacement Parts
Revision Date: 12/10/2014 Page 87 of 111
