Electrical - Proximity Switch / Shaft Encoder
Balloon No. Item Description Identifier
13.1 00060175 PROXIMITY SWITCH,CONNECTOR A
13.2 00022472
FEMALE ANGLED CONNECTOR M12 4-POLE, 4-PIN
FEMALE ANGLED M12 CONN. 4 POLE 90 DEG
A
15.1 00023779
CONTROLFLEX-COUPLING CPS 15/2,
CONTROLFLEX-COUPLING CPS 15/2 10 / 10
BOREHOLE
B
15.2 00160305
INCREMENTAL ENCODER, INCREMENTAL
ENCODER ZI58/32768
A
Electrical Components Replacement Parts
Proximity Switch Detail X
Shaft Encoder Detail Y
